Welding helmet p550 black/green, automatic darkening, DIN 4 / 9-13

The sensitivity of the sensors can be adjusted for the welding process and working conditions. The outer protection plate provides optimal protection against spatter and welding smoke. The switching time from dark to light can be regulated using the delayed opening function. The helmet offers unbeatable comfort thanks to the combination of optimal weight distribution and the convenient, adjustable head band. The helmet has a true-to-colour shade cartridge for realistic colour perception. Protection levels inactive: Protection level 4 active: Protection levels 9-13 UV/IR radiation is always filtered out in accordance with DIN standards Optimised air flow and smoke-repellent Eye protection: Maximum UV and IR protection at all protection level settings Sensors: Three sensors Classification EN 379: 1/1/1/2 Classification EN 175: B (120 m/s impact resistance) Switching time from light to dark: 0.100 ms at room temperature, 0.100 ms at +55 degrees Switching time from dark to light: 0.05-1.0 sec., infinitely variable selection Usage temperature: -10 to +70 degrees Power supply: Solar cells and batteries (CR 2032) - no need to switch on and off

Application: area: Electrode welding (stick welding, SMAW) MIG/MAG (gas metal arc welding, GMAW) GMAW high-performance welding Flux-core welding Some TIG welding

application: s, > 28 A welding current Plasma welding Micro-plasma welding Plasma cutting

Innritan verður skjótt tøk — fá prísir við at seta teg í samband við okkum: a4@a4.fo
Vørunummar0687108550
EAN4029484510054
Cassette height90 mm
Cassette thickness7 mm
Cassette width110 mm
Cassette width x cassette height x cassette thickness110 x 90 x 7 mm
ColourGreen
SupplierRECA NORM


The sensitivity of the sensors can be adjusted for the welding process and working conditions. The outer protection plate provides optimal protection against spatter and welding smoke. The switching time from dark to light can be regulated using the delayed opening function. The helmet offers unbeatable comfort thanks to the combination of optimal weight distribution and the convenient, adjustable head band.

The helmet has a true-to-colour shade cartridge for realistic colour perception.

Protection levels
inactive: Protection level 4
active: Protection levels 9-13

UV/IR radiation is always filtered out in accordance with DIN standards
Optimised air flow and smoke-repellent

Eye protection: Maximum UV and IR protection at all protection level settings
Sensors: Three sensors
Classification EN 379: 1/1/1/2
Classification EN 175: B (120 m/s impact resistance)
Switching time from light to dark: 0.100 ms at room temperature, 0.100 ms at +55 degrees
Switching time from dark to light: 0.05-1.0 sec., infinitely variable selection
Usage temperature: -10 to +70 degrees
Power supply: Solar cells and batteries (CR 2032) - no need to switch on and off

Application area:

  • Electrode welding (stick welding, SMAW)
  • MIG/MAG (gas metal arc welding, GMAW)
  • GMAW high-performance welding
  • Flux-core welding
  • Some TIG welding applications, > 28 A welding current
  • Plasma welding
  • Micro-plasma welding
  • Plasma cutting

Advantages:



  • Fully automatic dimming, protection levels can be adjusted from DIN 9-13
  • Extremely rapid switching from light to dark in 2 milliseconds
  • Opening delay — switching time from dark to light can be set to "slow" or "fast"
  • Solar technology and batteries — no need to switch on and off
  • Permanent eye protection
  • UV/IR rays are always filtered according to DIN standards
  • Optimised air flow and smoke-repellent
  • Spoilers prevent damage to the glass in the event of it falling out
  • Comfortable headband
  • Sensitivity regulation
  • Operating unit outside the helmet
