sebS pan hd drill.scr, window const, sim to DIN 7504-N yell-galv., H 2 3.9 x 16

Field of Application: Connecting the internal bracing to the plastic window profile. Screwing joining plates or angle brackets onto the aluminium window. Advice: Minimum screw length = clamping force + material thickness + drill bit tip length + 8 mm. Do not use the screw in applications with direct exposure to the weather or in wet rooms with atmospheres containing chlorine gas.

Innritan verður skjótt tøk — fá prísir við at seta teg í samband við okkum: a4@a4.fo
Vørunummar021103916
EAN4029484050291
Construction product0 - not applicable
Diameter3.9 mm
DIN7504 similar
Drill tip length6 mm
Head diameter7.5 mm
SupplierRECA NORM

Field of Application:

Connecting the internal bracing to the plastic window profile. Screwing joining plates or angle brackets onto the aluminium window.

Advice:

Minimum screw length = clamping force + material thickness + drill bit tip length + 8 mm.

Do not use the screw in applications with direct exposure to the weather or in wet rooms with atmospheres containing chlorine gas.
