Vit dagføra vøruupplýsingarnar. Vit fara ígjøgnum allar vørulýsingarnar í vørusavninum. Upplýsingarnar um nýtsluøki og tilfar, sum vøran kann brúkast til, kunnu vera skeivar, meðan vit skráseta rætta tilfarið fyri hvørja vøru. Ert tú í iva, spyr tín kontaktpersón hjá A4.
- Aluminium
- Plast
Connecting the internal bracing to the plastic window profile. Securing metal fittings if drilling through the bracing of the plastic window. Screwing joining plates or angle brackets onto the aluminium window. Securing metal fittings onto the aluminium window profile.
Góð ráð
- Minimum screw length = clamping force + material thickness + drill bit tip length + 8 mm.
- Do not use the screw in applications with direct exposure to the weather or in wet rooms with atmospheres containing chlorine gas.
Faklig nærlýsing
| Diameter | 3.9 mm |
| DIN | 7504 similar |
| Drill tip length | 6 mm |
| Head diameter | 7.5 mm |
| Head height | 2.3 mm |
| Head type | Countersunk head |
| Internal drive | H2 |
| Length | 16 mm |
| Material | Hardened steel |
| Max. material thickness | 4.0 mm |
| Min. material thickness | 0 mm |
| Min./max. material thickness | 0-4.0 mm |
| Surface | Zinc plated |
Væntað veiting: 29.–30. sep.
Bílegg í seinasta lagi mikudagin kl. 23:59 · bíleggingin verður send til Reca hósdagin
sebS cntrsnk hd dr.sc., window con., sim. to DIN 7504-P-H, galv., H 2, 3.9 x 16
Field of Application: Connecting the internal bracing to the plastic window profile. Securing metal fittings if drilling through the bracing of the plastic window. Screwing joining plates or angle brackets onto the aluminium window. Securing metal fittings onto the aluminium window profile. Advice: Minimum screw length = clamping force + material thickness + drill bit tip length + 8 mm.
| Vørunummar | 0212039161 |
| EAN | 4029484279753 |
| Pakkieind | pk (1000 stk) |
| Diameter | 3.9 mm |
| DIN | 7504 similar |
| Drill tip length | 6 mm |
| Head diameter | 7.5 mm |
| Head height | 2.3 mm |
| Veitari | RECA NORM |
