Drill - screw in - done The screw anchor is an innovative fastening system for securing assembly parts to concrete and other solid masonry. With its cutting-teeth design, the screw anchor cuts a thread in the drill hole as it is screwed in, creating a connection with mechanical interlocking and no expansion pressure.
Fyrimunir
- Shallow drill hole depths and small drill hole diameters
- Cutting teeth at the front of the anchor ensure minimal tightening torque
- No expansion effect, therefore minimal spacing and edge distance
- Quick and simple in-place installation, can be easily inserted by mechanical means
- Immediate load-bearing capacity - no waiting
- Fastening can be fully removed again
- No torque control required
- Wide range of uses due to numerous versions
- Attractive appearance
Faklig nærlýsing
| Anchor length (l) | 105 mm |
| Anchor size | 8 |
| Connection thread | M10 x 30 |
| External drive | WS7 |
| Material | Stainless steel A4 |
| Max. recommended power output for setting tool | 300 Nm |
| Nominal drill-bit diameter (d 0) | 8 mm |
| Surface | Plain |
| Thread diameter | 12.0 mm |
Væntað veiting: 29.–30. sep.
Bílegg í seinasta lagi mikudagin kl. 23:59 · bíleggingin verður send til Reca hósdagin
Screw anchor with external thread TSM 8x105 ET M10x30 AF 7 A4
Drill - screw in - done The screw anchor is an innovative fastening system for securing assembly parts to concrete and other solid masonry. With its cutting-teeth design, the screw anchor cuts a thread in the drill hole as it is screwed in, creating a connection with mechanical interlocking and no expansion pressure.
| Vørunummar | 0900508105 |
| EAN | 4066115042010 |
| Pakkieind | pk (50 stk) |
| Anchor length (l) | 105 mm |
| Anchor size | 8 |
| Connection thread | M10 x 30 |
| External drive | WS7 |
| Material | Stainless steel A4 |
| Veitari | RECA NORM |
