- Betong
Multiple attachment of non-load-bearing systems with approval • In cracked and non-cracked concrete • E.g. lightweight ceiling cladding and suspended ceilings, pipes, wire hangers etc. • For use in reinforced or non-reinforced normal weight concrete with a concrete compressive strength of min. C12/15 and max. C50/60 in accordance with EN 206-1:2000-12 May only be used in dry indoor room conditions.
Fyrimunir
- Quick and easy installationLess drilling required thanks to reduced effective anchorage depth of 25 mmEasy insertion: Simply hammer in - no torque requiredNo special drills or setting tools required
- In-place installation
- Minimal spacing and edge distance
- Elegant, attractive design
- Torque-controlled expansion anchor - expands when subjected to load
- Compatible with both M8 and M10 threaded rods thanks to step thread
Góð ráð
- Anchors in a redundant non-structural system in concrete: European Technical Approval ETA-11/0339
- Fire resistance: R30, R60, R90, R120 (base material: concrete C20/25 to C50/60): Technical report TR 020 "Evaluation of anchorages in concrete concerning resistance to fire" (included in ETA-11/0339)
- Thread length M8 = 7 mm
- Thread length M10 = 10 mm
- Sleeve size = SW 13
Faklig nærlýsing
| Anchor diameter | 6 mm |
| Anchor diameter x anchor length (l) | 6 x 58 mm |
| Anchor length (l) | 58 mm |
| Drill hole depth (h 0) | 35 mm |
| Effective anchoring depth (h ef) | 25 mm |
| Material | Steel |
| Minimum component thickness (h min) | 80 mm |
| Nominal drill-bit diameter (d 0) | 6 mm |
| Surface | Zinc plated |
| Through-hole in the component to be connected (d f) | 7 mm |
Væntað veiting: 29.–30. sep.
Bílegg í seinasta lagi mikudagin kl. 23:59 · bíleggingin verður send til Reca hósdagin
N-M 6-25/58 M8/10 nail anchor with M8 and M10 step thread zn pl steel 6x58
Application: area: Multiple attachment of non-load-bearing systems with approval In cracked and non-cracked concrete E.g. lightweight ceiling cladding and suspended ceilings, pipes, wire hangers etc. For use in reinforced or non-reinforced normal weight concrete with a concrete compressive strength of min. C12/15 and max. C50/60 in accordance with EN 206-1:2000-12 May only be used in dry indoor room conditions.
Field of Application: Suspended ceilings, pipes, cladding, cable trays
| Vørunummar | 0904002658 |
| EAN | 4029484931965 |
| Pakkieind | pk (100 stk) |
| Anchor diameter | 6 mm |
| Anchor diameter x anchor length (l) | 6 x 58 mm |
| Anchor length (l) | 58 mm |
| Drill hole depth (h 0) | 35 mm |
| Effective anchoring depth (h ef) | 25 mm |
| Veitari | RECA NORM |
