Application area:

Multiple attachment of non-load-bearing systems with approval

• For use in cracked concrete (tension zone) and non-cracked concrete (compression zone)
• E.g. lightweight ceiling cladding and suspended ceilings, pipes, cable trays, metal profiles, perforated strips, wire hangers, vernier hangers, wooden strips, wooden laths, square timbers etc.
• For use in reinforced or non-reinforced normal weight concrete with a concrete compressive strength of min. C12/15 and max. C50/60 in accordance with EN 206-1:2000-12

Can be used outdoors (including in industrial atmospheres and coastal areas) or in wet rooms.

Field of Application:

Suspended ceilings, pipes, cladding, cable trays

Advantages:

The nail anchor offers the benefits of a stud anchor while also being easy to install; the nail anchor is simply knocked into the drill hole through the attachment. No subsequent torque is required, not even for the threaded version.

Quick and easy installation

• Less drilling required thanks to reduced effective anchorage depth of 25 mm
• Easy insertion: Simply hammer in - no torque required
• No special drills or setting tools required

In-place installation

Minimal spacing and edge distance

Elegant, attractive design

Load-controlled expansion anchor. Expands when subjected to load

Advice:

• Anchors in a redundant non-structural system in concrete: European Technical Assessment ETA-11/0240
• Fire resistance: R30, R60, R90, R120 (base material: concrete C20/25 to C50/60): Technical Report TR 020 "Evaluation of anchorages in concrete concerning resistance to fire" (included in ETA-11/0240)
