Field of Application

• Insulated + uninsulated wire end ferrules • 10/16/25 mm² • Number of nests: 3

Vørulýsing

Bronzed pliers with non-slip plastic sleeves • For solderless electrical connections • Precision inserts and force stop function (can be released) for consistent high crimping quality • Crimping pressure precisely set (calibrated) at factory, adjustable • Two-handed operation for easy crimping of large conductor cross-sections • Special grade chromium-vanadium electric steel, oil-hardened • With non-slip plastic sleeves

Fyrimunir

Good handling thanks to balanced centre of gravity, angled head and ergonomically shaped handles
Compared to commercially available crimping tools, the manual force is reduced by up to 30% using a lever transmission

Design

Side insertion

Faklig nærlýsing

Connector type	Wire end ferrules
Design	Side insertion
Height	26 mm
Length	250 mm
Material	Chrome-vanadium steel, hardened
Material of handle	1-component plastic
Max. wire cross section	25 mm²

Min. wire cross section	10 mm²
Min./max. wire cross section	10-25 mm²
Number of crimping points	3
Profile shape	Wave profile
Surface	Burnished
Weight	618 g
Width	78 mm

Væntað veiting: 29.–30. sep.

Bílegg í seinasta lagi mikudagin kl. 23:59 · bíleggingin verður send til Reca hósdagin

Crimping tool for wire end ferrules, 250 mm with non-slip plastic ferrules

Vørunummar	0695410020
EAN	4003773025498
Pakkieind	1 stk
Connector type	Wire end ferrules
Design	Side insertion
Height	26 mm
Length	250 mm
Material	Chrome-vanadium steel, hardened
Veitari	RECA NORM
