Cemented carbide milling bits, SKM, conical, 12 x 25 x 6 mm

Conical shape DIN code SKM

Field of Application: Solid cemented carbide head on dia. 6 mm HSS shaft (soldered), with head dia. 6 mm made entirely of solid carbide. Precision manufacture on ultra-modern CNC grinding machines ensures accurate and uniform toothing with optimal tooth sharpening angle. Recommended cutting speed v = 500-960 m/min. Calculation of rotation speed n (min): n = (v x 1000) / d x 3.1415 Optimal economic results are achieved by applying the highest possible rotation speed.

Innritan verður skjótt tøk — fá prísir við at seta teg í samband við okkum: a4@a4.fo
Vørunummar0678181225
EAN4029484304561
Construction product0 - not applicable
Cutting edge length25.0 mm
Diameter12.0 mm
Length70.0 mm
TypeCone shape
SupplierRECA NORM

Conical shape DIN code SKM

Field of Application:

  • Solid cemented carbide head on dia. 6 mm HSS shaft (soldered), with head dia. 6 mm made entirely of solid carbide. Precision manufacture on ultra-modern CNC grinding machines ensures accurate and uniform toothing with optimal tooth sharpening angle. Recommended cutting speed v = 500-960 m/min.
  • Calculation of rotation speed n (min): n = (v x 1000) / d x 3.1415
  • Optimal economic results are achieved by applying the highest possible rotation speed.

Advantages:

  • Maximum chipping of high-strength and tough materials
  • Rough and finish milling on hand-operated drive machines
  • Application on stationary machines also possible
  • The universal toothing type with stronger teeth is suitable for machining stainless steels, steels of greater hardiness, grey cast iron, welding seams, hard plastics and hardened steels.

Type:

Cone shape
