- Betong
For securing supports, beams, metal structures, brackets, cable conduits, mounting rails, suspended ceilings etc. to uncracked normal weight concrete with a strength class of ≥ C20/25 and ≤ C50/60, also for use outdoors or in wet rooms if conditions are not particularly aggressive.
The perfect anchor for quick, reliable fixings in uncracked concrete and for suspended ceilings The stud anchor B A4 is particularly suitable for time-saving in-place installation in uncracked concrete, and for suspended ceilings. The reduced embedment depth expands the range of applications, e.g. for reinforcement chamfers and for low loads.
Fyrimunir
- High permissible loads, low spacing and edge distance
- Quick and easy in-place installation
- Immediate load-bearing capacity - no waiting
- The long thread allows anchors to be used for different clamping widths. Furthermore, it allows stand-off installations and other applications requiring larger clamping lengths or reduced effective anchorage depths.
- Reduced effective anchorage depths possible, e.g. for reinforcement chamfers or for low loads
- Three effective anchorage depths for flexible use
Faklig nærlýsing
| Anchor diameter | 10 mm |
| Anchor diameter x anchor length (l) | 10 x 90 mm |
| Anchor length (l) | 90 mm |
| Diameter | 10.0 mm |
| Drill hole depth (h 1) | 70 mm |
| Drill hole depth reduced (h 1, red) | 65 mm |
| Effective anchoring depth (h ef) | 48 mm |
| Effective anchoring depth reduced (h ef, red) | 42 mm |
| Embedding depth (h nom,red) | 56 mm |
| Embedding depth (h nom) | 62 mm |
| Length | 90.0 mm |
| Material | Stainless steel A4 |
| Max. attachment height (t fix) | 15 mm |
| Max. attachment height reduced (t fix, red) | 21 mm |
| Nominal drill-bit diameter (d 0) | 10.00 mm |
| Thread diameter | 10 mm |
| Thread diameter x thread length (metric thread) | 10 x 45 mm |
| Thread length (metric thread) | 45 mm |
| Thread type | Metric thread |
| Width across flats | 17 mm |
Væntað veiting: 29.–30. sep.
Bílegg í seinasta lagi mikudagin kl. 23:59 · bíleggingin verður send til Reca hósdagin
B stud anchor, A4, M10 x 15-21/90
The perfect anchor for quick, reliable fixings in uncracked concrete and for suspended ceilings The stud anchor B A4 is particularly suitable for time-saving in-place installation in uncracked concrete, and for suspended ceilings. The reduced embedment depth expands the range of applications, e.g. for reinforcement chamfers and for low loads.
| Vørunummar | 0909910015 |
| EAN | 4029484278589 |
| Pakkieind | pk (50 stk) |
| Anchor diameter | 10 mm |
| Anchor diameter x anchor length (l) | 10 x 90 mm |
| Anchor length (l) | 90 mm |
| Diameter | 10.0 mm |
| Drill hole depth (h 1) | 70 mm |
| Veitari | RECA NORM |
