Góð ráð
- Do not use the screw in applications with direct exposure to the weather or in wet rooms with atmospheres containing chlorine gas.
Design
With spring catch and security bracket
Faklig nærlýsing
| Connection thread | M10 |
| Design | With spring catch and security bracket |
| DIN | 71802 |
| Form | CS |
| Length | 19 mm |
| Length 2 | 16 mm |
| Length from centre of ball to end of ball socket | 35 mm |
| Material | Steel |
| Nominal diameter | 10 mm |
| Standards | DIN 71802 |
| Surface | Zinc plated |
| Thread type | Metric thread |
| Thread type x nominal diameter | M10 |
Væntað veiting: 29.–30. sep.
Bílegg í seinasta lagi mikudagin kl. 23:59 · bíleggingin verður send til Reca hósdagin
Angle joint, DIN 71802, galvanised, type CS 16 M10
Design: With spring catch and security bracket Advice: Do not use the screw in applications with direct exposure to the weather or in wet rooms with atmospheres containing chlorine gas.
| Vørunummar | 026851019 |
| EAN | 4029484064953 |
| Pakkieind | pk (5 stk) |
| Connection thread | M10 |
| Design | With spring catch and security bracket |
| DIN | 71802 |
| Form | CS |
| Length | 19 mm |
| Veitari | RECA NORM |
