Design

With lamellar joint

Technical specifications

Beam dimensions	68.8 mm x 28.8 mm
Beam height	68.8 mm
Beam width	28.8 mm
Design	With lamellar joint
EN standard	131
Height, vertical	6.06 m
Load-carrying capacity	150 kg
Material	Aluminium
Max. length as standard ladder	6.44 m
Max. reaching height as standard ladder	7.04 m
Max. standing height as standard ladder	5.04 m
Max. working height as standard ladder	6.54 m
Min. length as standard ladder	3.64 m
Min./max. length as standard ladder	3.64-6.44 m
Number of rungs	4 x 6
Rung depth	25 mm
Rung dimensions	25 x 25 mm

Rung distance	280 mm
Rung height	25 mm
Standards	EN 131
Step ladder with sliding part Min./max. height vertical	1.77-3.10 m
Step ladder with sliding part: Max. height vertical	3.10 m
Step ladder with sliding part: Max. length	3.14 m
Step ladder with sliding part: Max. standing height	2.41 m
Step ladder with sliding part: Min. height vertical	1.77 m
Step ladder with sliding part: Min. length	1.78 m
Step ladder with sliding part: Min./Max. length	1.78-3.14 m
Step ladder with sliding part: Stride length	2.08 m
Transport depth	210 mm
Transport length	1880 mm
Transport length x transport width x transport depth	1880 x 705 x 210 mm
Transport width	705 mm
Weight	19 kg

Expected delivery: 29–30 Sep

Order by Wednesday 23:59 · sent to Reca on Thursday

Alu professional telescopic ladder 4x6 rungs

Design: With lamellar joint

Article number	4550111457
EAN	4066115025532
Pack unit	1 pc
Beam dimensions	68.8 mm x 28.8 mm
Beam height	68.8 mm
Beam width	28.8 mm
Design	With lamellar joint
EN standard	131
Supplier	RECA NORM
